OPTICAL
Light source : OSRAM 140W
Beam angle : 1.7°
Front lens diameter : 128mm
Luminance : 200000lux@10M
EFFECTS
Color wheel : 14 color + Blank, Bi-direction rainbow effect
CMY infinite colour mixing
Static gobo wheel : 17 fixed gobo +1 Blank, Bidirectional rotation effect
Frost : individual soft light
Prism : 8 facet prism+24 facet prism, Multiple prism combination
Dimmer : 0 to 100% linear dimmer
Strobe : Electronic pulse strobe and random strobe
Focus : Motorized focus
CONTROL
Channel mode : 16CH, see channel table for details
Control protocol : DMX 512、RDM
DMX and RDM connectors : Locking 3 pin or 5 pin XLR IN/OUT
Power connector : Seetronic one in one out
Hanging system : foldable light hook
Display : LCD Lattice screen
SOFTWARE
Upgrade : DMX or USB
temperature control : Intelligent temperature control to ensure long lifespan of Lamp
PAN/TILT MOVEMENT
Pan/Tilt : 540°/270°
POWER
Voltage : AC 100-240V 50/60Hz
Power : 320W PF:>0.98
SIZE & WEIGHT
Light dimension : 329 x 222 x 516mm
N.W : 14.6kg/pcs
Carton dimension : 410 x 290 x 625mm
G.W with carton : 18.2kg/pcs
Flycase dimension : 850 x 660 x 725(mm)
G.W with fly case : 109.6kg (4 in 1)
OTHERS
IP rate : IP66
Working environment : -10℃ ~ 40℃
Maximum temperature of fixture body surface : 80℃
Maximum on-line quantity : 4pcs/100V 8pcs/220V
Maximum current : 3.2A/100V; 1.46A/220V
